HZS50 Concrete Batching Plant Zoom in
  • Name:

    HZS50 Concrete Batching Plant

  • Minimum Order Quantity:1 Set/Sets
  • Supply Ability:15 Set/Sets per Month
  • Payment Terms:L/C,T/T

Product Description

HZS50 Concrete Batching Plant Quick Details

This HZS50 Concrete batching plant adopts JS series twin-shaft compulsory mixer, producing homogeneous concrete with good quality in short time. The easily-damaged parts could last for long time, convenient to operate and maintain. It applied the latest design for electronic weighing, computer control and digital display. The electronic weighing system has a buffer device and automatic volume compensation with high accuracy. The batching machine sand and gravel feeding system applied inclined belt with great width, the maintenance walkways is installed. It is the ideal choice for producing high-quality concrete.

Brand Name:HM
Model Number:HZS50
Condition:New
Capacity:50m3/h
Main Mixer:JS1000
Power of Main Mixer: 37kw
Feeding Mode:Lifting hopper
Mixing Time:60s
Max Aggregate Size:60/80mm
Discharging Height: 3.8m(for customers choice)
Control Mode: Automatic Control System/Central Console Control

Packaging and delivery of ready-mixed concrete mixing plant

Packaging Detail:container
Delivery Detail:12 days

HZS50 Concrete Batching Plant Specifications:

1.Competitive price and quality
2.Compact structure,reliable performance
3.Warranty: 12Month





The layout for HZS50 complete concrete batching plant:

Main features of HZS50 concrete batching plant :

1. Adopt combined structure and modular unit, convenient to install and remove;
2. Mixing and aggregate lifting system adopt JS1000 double-shaft compulsory concrete mixer which offers high quality and efficient mixing;
3. Aggregate batching system adopts PLD1600 concrete batcher which offers efficient and accurate measurement;
4. Powder lot is electronic measured, highly accurate dosing;
5. Water is flow-metering, simple and practical, highly accurate dosing.



Main technical data of HZS50 concrete batching plant

Type

HZS50

Productivity in theory

50m³/h

Mixer

JS1000

Total power

110KW

Maximum aggregate diameter

80mm

Aggregate feeding method

Conveyor belt

Batcher

PLD1600

Aggregate bins volume

3x13m³

Aggregate weighing

3000kg ±2%

Cement weighing

600kg ±1%

Fly-ash weighing

400kg ±1%

Water weighing

400kg ±1%

Additive weighing

50kg ±1%

Overall dimension(during operating)

        (LXWXH)

33.8mX14.8mX10.8m



Discharging height

3.8m

Total weight

46T

Control

Fully automatic

Cement silo(optional)

Required on clients' demand, 50T,100T available

Cement screw(optional)

Each cement silo equipped with one φ219 screw
