Concrete Batching Plant HZS50 VS HZS60

HZS50 and HZS60 are two common concrete batching plant models. They are both medium-sized concrete batching plants and are equipped with the same type of concrete mixers. The core differences between HZS50 and HZS60 concrete batching plants are mainly reflected in the feeding method, production efficiency, applicable scenarios and configuration costs.


1. Comparison of core technical parameters
- Production efficiency
The theoretical productivity of HZS50 concrete batching plant is 50m³/h, and that of HZS60 concrete batching plant is 60m³/h. Although both are equipped with JS1000 twin-shaft forced concrete mixers (nominal capacity 1000L), HZS60 concrete batching plant optimizes material conveying efficiency through a belt feeding system, while HZS50 uses bucket-lift feeding, with slightly lower single feeding volume and speed.
- Feeding method and floor space
HZS50 concrete batching plant: bucket-lift feeding, compact structure, small floor space (about 200㎡), suitable for small and medium-sized projects with limited space.
HZS60 concrete batching plant: Belt feeding, high conveying stability and low failure rate, but it needs to be equipped with a belt conveyor and a closed conveying corridor, covers a large area (about 300㎡), and is suitable for large-scale production.
- Energy consumption and power
The total installed power of HZS50 concrete batching plant is about 95kW, and the power consumption is about 95 degrees per hour; the total power of HZS60 concrete batching plant is 109kW, and the power consumption is about 110 degrees per hour. The energy consumption of HZS60 concrete batching plant is higher, and the long-term operating cost needs to be considered.


2. Configuration and applicable scenarios
- Basic configuration differences
Batching machine: HZS50 concrete batching plant usually uses the PLD1600 four-bin cumulative weighing batching machine, while HZS60 may be upgraded to the PLS1600 four-bin separate metering batching machine, which has higher metering accuracy (±1%).
Environmental protection design: HZS60 concrete batching plant is often equipped with a pulse dust collector, a closed belt conveyor and a closed system outside the main engine, which meets environmental protection requirements.
Control system: HZS60 concrete batching plant mostly adopts dual computer control system, supports automatic fault detection and dynamic production monitoring, and has a higher degree of automation.
- Applicable scenarios
HZS50 concrete batching plant: Suitable for rural infrastructure, small commercial concrete stations and temporary projects, such as township roads, small bridges, etc., with low investment cost (equipment is about 30,000-50,000 US dollars, total cost is 40,000-60,000 US dollars), and short payback period.
HZS60 concrete batching plant: Suitable for urban commercial concrete centers, large bridges, airports and other projects, with an annual production capacity of up to 120,000 cubic meters, but the initial investment is relatively high (50,000-90,000 US dollars).


3. Maintenance and operation costs
- Maintenance convenience
The bucket lift structure of HZS50 concrete batching plant is simple to maintain, and the cost of replacing accessories is low; the belt conveyor of HZS60 concrete batching plant needs to regularly check the belt wear and tension, and the maintenance cost is slightly higher.
- Accessories and after-sales
The core components of both (such as JS1000 concrete mixer) are highly versatile, but the belt conveyor accessories of HZS60 concrete batching plant (such as electric rollers and rollers) are replaced more frequently. Mainstream manufacturers (such as Haomei) provide installation and commissioning, technical training and lifetime accessories support.


4. Investment decision-making recommendations
- Choose HZS50 concrete batching plant: If the project cycle is short, the output demand is low (such as less than 300 cubic meters per month), and the budget is limited, HZS50 concrete batching plant has a higher cost-effectiveness and is suitable as an entry-level device.
- Choose HZS60 concrete batching plant: If long-term large-scale production is required (such as more than 1,000 cubic meters per month), and environmental protection and automation are emphasized, HZS60 concrete batching plant has more advantages in efficiency and stability, and a higher long-term return rate.


HZS50 concrete batching plant is suitable for small and medium-sized projects, while HZS60 concrete batching plant is suitable for medium and large projects. HZS60 concrete batching plant usually requires more complex configuration to meet higher production needs.
